Sabre P Low-Cost Process Digital Panel Meter
PD603
Model
PD603-6R0-1
Product Type
Sabre P 1/8 DIN Process Digital Panel Meter
Input(s)
4-20 mA, ± 10 V (Field Selectable)
Number of Inputs
1
Display
Red LED, 7 Segments, 4 Digits (-1999 to 9999), 0.56" (14.2 mm) High
Transmitter Power
24 VDC @ 200 mA
Output(s)
None
Operating Temperature Range
0 to 65°C (32 to 149°F)
Serial Communications
None
Math Functions
None
Front Panel
UL Type 4X, IP65, NEMA 4X
DIN Size
1/8 DIN
Weight
9 oz (241 g)
Approvals
UL & C-UL Listed. E160849; UL 508 Industrial Control Equipment, CE
Warranty
1 Year
$256.00
Inches (mm)
Documentation & Resources
No software found for this product.
PDA2322
Plastic UL Type 4X Enclosure with (1) Vertical and (1) Horizontal 1/8 DIN Cutouts
PDA3414
Plastic UL Type 4X Enclosure with (1) Vertical and (1) Horizontal 1/8 DIN Cutouts
PDA2821
Plastic UL Type 4X Enclosure with (1) Vertical and (1) Horizontal 1/8 DIN Cutouts
PDA2604-1C
Stainless Steel UL Type 4X Enclosure with (1) Centered Horizontal 1/8 DIN Cutout
PDA2604-2C
Stainless Steel UL Type 4X Enclosure with (2) Centered Horizontal 1/8 DIN Cutouts
PDA2604-3C
Stainless Steel UL Type 4X Enclosure with (3) Centered Horizontal 1/8 DIN Cutouts
PDA2622
Stainless Steel UL Type 4X Enclosure with (1) Vertical and (1) Horizontal 1/8 DIN Cutouts
