UL Type / NEMA 4X Plastic Enclosure Series
PDA2301
Models in stock
from $135.00
PDA2300 NEMA 4X, C-UL listed enclosures feature a hinged door in which meters are mounted so all programming and operational functions are available without opening the enclosure. The PDA2300 can house between one and ten meters in either horizontal or vertical orientation. A dual orientation enclosure for two 1/8 DIN devices is also available. All PDA2300 enclosures are outfitted with stainless-steel hinges and clasps. Enclosures and meters are ordered and packaged separately.
Quick Downloads
The PDA2300 series of economical plastic UL Type / NEMA 4X enclosures for meters and controllers provides a convenient way to mount up to ten Precision Digital meters / controllers to walls and other vertical structures. Many of these enclosures also have room for additional devices like a light/horn and a 24 V transmitter power supply.
Sub-panels are available to mount additional devices to the base of the enclosure. These enclosures come pre-cut with horizontal or vertical 1/4, 1/8, or 1/16 DIN cutouts, or they can be ordered with no cutouts. The instruments are mounted in the door of the enclosure thus allowing for programming and operation of the instrument. Mounting hardware is provided. The door is hinged and secured with stainless steel latches. Enclosures, meters/controllers and accessories are ordered and packaged separately.
